Vertical Jump

The Brower Vertical Jump is an intuitive way to measure an athletes jump performance. Giving you instant height measurements so you can quickly test a high volume of athletes. No more counting sticks or cheating the pad.


High Throughput

Easily and accurately measure up to 5 athletes per minute. With its infrared sensing technology athletes can quickly set their reach then measure their jump height.

Vert Jump hand.jpg


0.2 inches (0.5 mm) jump resolution.

48” height allows for a wide range of athlete sizes without the need for adjusting the unit’s position.

Measures every jump, not just the highest.

Large detection area, 10 inches deep by 4 inches wide.

Vertical Jump.jpg

Mounting Options

With the included clamps the Brower Vertical Jump can quickly be attached to backboards and doors or used with a stand. It can also be mounted to walls for a more permanent installation.


 Tutorial Video Series


 Technical Specifications

Length 52 inches
Detection Area 48" tall / 1-8" from the unit / 4" wide
Resolution 0.2"
Max Error +- 0.2"
Batt. Life 2000 Jumps (40 Hrs.) 30 Days on Standby
Shipping 12 lb / 4.5" x 58"
Unit Weight 9 lb
